MID-CGB

Continuous Gravimetric Blender powered by TRIDEXX™

All in one system for continuous gravimetric feeding of material that designed for simplicity, ease of use and quick to learn.

The CGB system is an all in one system for continuous gravimetric feeding of material and is designed for simplicity, ease of use and quick to learn.It comes equipped with hardware and software to handle the refill system for multiple ingredients. The large easy to see buttons and numbers on the touch screen make it easy to operate in all types of light conditions and ensures the operator has a large button area to make changes or adjustments in the operation of the blender. CGB is the artful mix of simplicity and utility while maintaining leading edge control technology.

Continuous

Feeding

Gravimetric

Type

2 Year

Warranty

  • Loss in Weight Gravimetric Auger Feeder
  • Gravimetric control for Virgin, Re-grind and Color
  • Individual material feed rates of up to 110Kg/hr for the
  • Color touch screen operator interface
  • Dynamic Adaptive Control algorithm
  • Recipes and material name database
  • Data acquisition through wired Ethernet
  • Pneumatic Slide Gate Control for Regrind and Raw material
  • Stepper Motor Drive for precise metering
  • Hopper capacity of 5000gr each
  • Material Bridging Vibrator
  • Injection and Extrusion modes
  • Extrusion follow up mode
  • Automatic Calibration
  • Automatic adjustment to color density changes
  • Automatic storage of settings during power down
  • Low level and No Flow™ Alarm
